Affordable PCB Prototypes & Assembly Services

PCB quality control and flying probe testing process

We provide high-quality, low-cost PCB prototypes and professional PCB assembly for global engineers and buyers. Reliable, fast, and cost-effective PCB solutions from 2-layer to multilayer, flexible, and rigid-flex boards.我们为全球工程师和买家提供高质量、低成本的 PCB 原型和专业 PCB 组装服务。从二层到多层、柔韧和刚性柔性板,提供可靠、快速且经济的 PCB 解决方案。

PCB prototypes and PCB assembly manufacturing process

Why Choose Us for Low-Cost PCB Prototypes

We balance affordable PCB prototypes with consistent, industrial-grade quality. Our advantages help you reduce costs while ensuring reliability:

  • Cost-Effective Pricing: PCB prototypes start at $10 with transparent pricing
  • Fast Turnaround: 24-hour quick-turn for 2-layer boards
  • Strict Quality: IPC standard, flying probe testing, full inspection
  • Global Delivery: Safe and economical shipping worldwide
  • Professional Support: Free DFM review and design optimization
PCB quality control and flying probe testing process

Factors That Impact PCB Manufacturing Cost

The price of PCB fabrication and assembly depends on design and material choices. Understanding these helps you optimize your budget.

Cost FactorImpact on Price
Board SizeLarger boards increase material cost
Layer CountMore layers raise complexity and cost
Material TypeFR4 is economical; specialty materials cost more
Turnaround TimeFaster delivery adds premium fees
Order QuantityBulk orders lower per-unit cost

Our PCB Fabrication & Assembly Services

2-Layer PCB Prototypes

Low-cost, fast PCB prototypes for simple circuits. Ideal for testing and initial development. Starting at $10.

Multilayer PCB Prototypes

4-layer to 64-layer high-precision boards for industrial, medical, and communication applications.

Flex & Rigid-Flex PCBs

Lightweight, durable flexible circuits for compact devices and wearable electronics.

PCB Assembly Services

Full SMT, THT, and turnkey PCB assembly with component sourcing and stencil support.

Multilayer PCB and flexible PCB prototype manufacturing

10 Tips to Reduce PCB Manufacturing Costs

  1. Minimize board size to save material
  2. Use standard FR4 material instead of high-cost substrates
  3. Reduce layer count when possible
  4. Avoid rush orders to eliminate premium fees
  5. Choose standard 1.6mm board thickness
  6. Use cost-effective surface finishes like HASL
  7. Simplify design to avoid HDI and impedance control
  8. Combine small orders for panelization savings
  9. Order in bulk for lower unit costs
  10. Request free DFM review to fix design issues early
PCB cost optimization and DFM review guide

How to Get a Free PCB Quote

Getting a quote for PCB prototypes and assembly is fast and simple:

  1. Send your Gerber files (RS-274X)
  2. Our engineers review design for DFM and cost
  3. Receive detailed quote within 24 hours
  4. Confirm and start production

Summary

We provide reliable, affordable PCB prototypes and PCB assembly with fast lead times, strict quality control, and global shipping. Our professional team supports you from design to delivery.

Start Your PCB Project Today

Get a free, no-obligation quote for PCB prototypes and assembly within 24 hours.

Request a Free Quote

Frequently Asked Questions

Q: What is the minimum price for PCB prototypes?
A: PCB prototypes start at $10 for small 2-layer boards.

Q: How fast can you deliver PCB prototypes?
A: 24-hour quick-turn is available for standard 2-layer PCB prototypes.

Q: Do you provide full PCB assembly services?
A: Yes, we offer full SMT and THT PCB assembly for prototypes and mass production.
